FULLY ENCLOSABLE TENTS

4x4 (Full Tent) 5x5 (Full Tent)
Floor dimensions 4m x 4m 5m x 5m
Height 2.8m 3.5m
Weight 75kg 115kg
Tube frame pressure 0.29 bar 0.29 bar
Inflation/deflation valves 22mm 1 1
Pressure safety valves Optional Optional
Doors 4 4
Netted Windows 8 8
Storm covers over Doors/windows Yes Yes
Packed dimension 1,3m x 0,6m x 0,6m 1,5m x 0,7m x 0,7m
Fabric
Cover and storm covers PVC coated Polyester fabric 400 gr/sqm PVC coated Polyester fabric 400 gr/sqm
Groundsheet PVC coated Polyester fabric 600 gr/sqm PVC coated Polyester fabric 600 gr/sqm
Netting over windows PVC coated Polyester netting PVC coated Polyester netting
Inflatable tubing (Inflatable boat fabric) PVC coated Polyester fabric 1000 grm/sqm PVC coated Polyester fabric 1000 grm/sqm

GAZEBO-STYLE TENTS

4x4 (Gazebo) 5x5 (Gazebo)
Floor dimensions 4m x 4m 5m x 5m
Height 2.8m 3.5m
Weight 55kg 80kg
Tube frame pressure 0.29 bar 0.29 bar
Inflation/deflation valves 22mm 1 1
Pressure safety valves Optional Optional
Packed dimension 1,3m x 0,6m x 0,6m 1,5m x 0,7m x 0,7m
Fabric
Groundsheet PVC fabric 600 gr/sqm PVC fabric 600 gr/sqm
Inflatable tubing(boat fabric) PVC fabric 1000 grm/sqm PVC fabric 1000 grm/sqm

CUSTOMISATIONS

ARK can provide custom branding and labelling
Additional securing points can be added.

4x4 5x5
Floor dimensions 4m x 4m 5m x 5m
Height 2.8m 3.5m
Weight 75kg 115kg
Tube frame 0.29 bar 0.29 bar
Inflation/deflation valves 22mm 1 1
Pressure safety valves Optional Optional
Doors 4 4
Netted Windows 8 8
Storm covers over Doors/windows Yes Yes
Packed dimension 1,3m x 0,6m x 0,6m 1,5m x 0,7m x 0,7m
Fabric
Cover and storm covers PVC coated Polyester fabric 400 gr/sqm PVC coated Polyester fabric 400 gr/sqm
Groundsheet PVC coated Polyester fabric 600 gr/sqm PVC coated Polyester fabric 600 gr/sqm
Netting over windows PVC coated Polyester netting PVC coated Polyester netting
Inflatable tubing(Inflatable boat fabric) PVC coated Polyester fabric 1000 grm/sqm PVC coated Polyester fabric 1000 grm/sqm
INFLATABLE BOATS
RETUBES
TENTS
LIFT BAGS
FENDERS
CUSTOM BUILDS
ACCESSORIES

CANOE, KAYAKS & TUBES

Crocs Gecko Alligators Kayaks Prawn Solo Adventurer

KICKBOAT

Wildfly V-Boat

WHITEWATER RAFTS

Zambezis Niles Crocs Catarafts

POWER BOATS

Seal Fishalots Fishducs Otters Minnows

RESCUE BOATS

Arkangels Rescue Crocs Rescue Niles
Lifejackets Pumps Throwlines
Dry Bags & Buckets Boat Spares Paddles & Oars

GECKO

APPLICATIONS

Canyoning / Kloofing / Tubing / Towing

A rugged mini rafting tube designed for canyoning also an excellent tow tube and lightweight fishing platform.

DESIGN PHILOSOPHY

Lightweight and extremely portable, the GECKO was built to be easily carried into remote gorges which demand it to be lightweight and super tough. Easily portaged inflated or deflated and capable of running the tightest of creeks. Built to commercial raft specifications, the GECKO will last anything you can throw at it or throw it at for that matter.

SPECIFICATIONS

STANDARD FEATURES

  • Built from commercial grade PVC
  • All welded construction
  • Two grab handles
  • Foam floor or airdeck options
  • 2 Tow D-rings
  • High flow rate inflation valves
  • Double skinned underside

DIMENSIONS AND TECHNICAL SPECIFICATIONS

Packed Size
and Weight		 55 x 22 x 20cm (5kg)
Length 1.1m
Width 0.90m
Tube Diameter 280mm Max
Carrying Power 1 person with day pack

COLOURS

Available in any combination of the colours listed below:

Tube Trim
Red Red
Yellow Yellow
Grey Grey
Royal Blue Royal Blue
Light Blue Light Blue
Navy Blue Navy Blue

CUSTOMISATIONS

  • Branding - full colour logos or standard lettering/numbering - you supply logos and artwork or let us do it for you
  • Additional carry handles
  • Additional D-rings for securing equipment
  • Material – ARK can supply rafts in different fabric specifications for particular applications (e.g. Polyurethane, and Poly/PVC blends)
  • Colours other than those in the colour table above are possible dependent on availability

If this is the boat you're after contact us.
