FULLY ENCLOSABLE TENTS

4x4 (Full Tent) 5x5 (Full Tent)
Floor dimensions 4m x 4m 5m x 5m
Height 2.8m 3.5m
Weight 75kg 115kg
Tube frame pressure 0.29 bar 0.29 bar
Inflation/deflation valves 22mm 1 1
Pressure safety valves Optional Optional
Doors 4 4
Netted Windows 8 8
Storm covers over Doors/windows Yes Yes
Packed dimension 1,3m x 0,6m x 0,6m 1,5m x 0,7m x 0,7m
Fabric
Cover and storm covers PVC coated Polyester fabric 400 gr/sqm PVC coated Polyester fabric 400 gr/sqm
Groundsheet PVC coated Polyester fabric 600 gr/sqm PVC coated Polyester fabric 600 gr/sqm
Netting over windows PVC coated Polyester netting PVC coated Polyester netting
Inflatable tubing (Inflatable boat fabric) PVC coated Polyester fabric 1000 grm/sqm PVC coated Polyester fabric 1000 grm/sqm

GAZEBO-STYLE TENTS

4x4 (Gazebo) 5x5 (Gazebo)
Floor dimensions 4m x 4m 5m x 5m
Height 2.8m 3.5m
Weight 55kg 80kg
Tube frame pressure 0.29 bar 0.29 bar
Inflation/deflation valves 22mm 1 1
Pressure safety valves Optional Optional
Packed dimension 1,3m x 0,6m x 0,6m 1,5m x 0,7m x 0,7m
Fabric
Groundsheet PVC fabric 600 gr/sqm PVC fabric 600 gr/sqm
Inflatable tubing(boat fabric) PVC fabric 1000 grm/sqm PVC fabric 1000 grm/sqm

CUSTOMISATIONS

ARK can provide custom branding and labelling
Additional securing points can be added.

4x4 5x5
Floor dimensions 4m x 4m 5m x 5m
Height 2.8m 3.5m
Weight 75kg 115kg
Tube frame 0.29 bar 0.29 bar
Inflation/deflation valves 22mm 1 1
Pressure safety valves Optional Optional
Doors 4 4
Netted Windows 8 8
Storm covers over Doors/windows Yes Yes
Packed dimension 1,3m x 0,6m x 0,6m 1,5m x 0,7m x 0,7m
Fabric
Cover and storm covers PVC coated Polyester fabric 400 gr/sqm PVC coated Polyester fabric 400 gr/sqm
Groundsheet PVC coated Polyester fabric 600 gr/sqm PVC coated Polyester fabric 600 gr/sqm
Netting over windows PVC coated Polyester netting PVC coated Polyester netting
Inflatable tubing(Inflatable boat fabric) PVC coated Polyester fabric 1000 grm/sqm PVC coated Polyester fabric 1000 grm/sqm

WILDFLY V-BOAT

SERIES

WILDFLY V-BOAT

The Wildfly V-Boat is distributed exclusively through Wildfly
Call 033 266698 or email
orders@wildfly.co.za

WILDFLY V-BOAT

The ARK WILDFLY V-BOAT is a premium quality kick boat / float tube that is rugged, light and portable, taking your fly into the most remote and inaccessible of places. The WILDFLY V-BOAT is the ultimate kick boat, designed by the ARK design team in consultation with top fly fisherman notably the passionate Neil Westerhof, to catch BIG FISH! ARK´s 22 years´ experience in building rugged inflatable boats and rafts for all kinds of conditions, has allowed us to design the ultimate, rugged kick-boat, with practical features, that will provide years of angling pleasure. Designed and manufactured in South Africa.

APPLICATIONS

For kick-boat fly fishing on rivers, lakes, lagoons, estuaries and dams.

DESIGN PHILOSOPHY

The philosophy ARK adopted was to design a premium quality, lightweight portable product that did not sacrifice on safety, stability, buoyancy and ruggedness. Two additional design considerations were to keep the angler as dry as possible with a higher seating position, and to use a multi chamber 1000g marine PVC tube, without the need for inner bladders. The tube has 3 separate air chambers; the air-floor has a further 1 chamber for additional safety and comfort. The WILDFLY V-BOAT is quick and easy to inflate and pack away, and can be packed wet.

The WILDFLY V-BOAT sports an inflatable floor and cloth backrest, extra wide 60cm strip tray, two removable accessory bags, carry handle at the front and additional D-rings on the tube to attach kit and accessories.

SPECIFICATIONS

STANDARD FEATURES

  • Air chambers: 4 (3 on the tube, and 1 for the seat)
  • 2 x Accessory bags with heavy duty zip
  • Carry handle at front
  • 2 x D-rings each side for accessories
  • Olive green tube and floor
  • Quick-release stabilizer bar
  • Strip line tray, with incorporated measuring scale to 60cm
  • Carrying capacity: 1 adult to 120kg
  • Includes hand pump, carry bag and repair kit
  • Kick boat weight: 10 kg, packed weight 12kg
  • Packed size: 90cm x 35cm x 35cm

DIMENSIONS AND TECHNICAL SPECIFICATIONS

Series
WILDFLY V-BOAT
Packed Size
and Weight
90 x 35 x 35cm (12kg)
Weight of boat 10kg
Length 1.75m
Width (inside) 47cm
Width (external) 109cm
Tube Diameter 31cm

COLOURS

Available in any combination of the colours listed below:

Tube Trim
Olive Green Olive Green
Blue Blue
Red Red
Camo Camo
Dark Grey Dark Grey

CUSTOMISATIONS

  • Branding - full colour logos or standard lettering/numbering - you supply logos and artwork or let us do it for you
  • Removable dual rod holder (removable Velcro/Webbing strap
  • Additional D-rings for securing equipment
  • Backpack option for carry bag
  • Clip on anchor bag at bow

If this is the boat you're after contact us.
